Bending machine is divided into manual bending machine, hydraulic bending machine and CNC bending machine. According to the synchronous mode, the 4-6 meter upper movable hydraulic press can be divided into: the torsion axis synchronization, the synchronization of the synchronous machine, and the electro hydraulic synchronization. Hydraulic bending machine according to the motion mode can be divided into: the upper and lower dynamic type. The bending machine belongs to the upper dynamic hydraulic bending machine.
4-6 meter bending machine using method
1, the first is the power, in the control panel to open the key switch, and then press the pump to start, so you will hear the sound of the oil pump. (the machine does not move at this time)
2, stroke adjustment, bending machine use must pay attention to adjust the stroke, before bending must test. The upper die down to the bottom of the bending machine must ensure that there is a gap between the thickness of the plate. Otherwise it will cause damage to the mold and machine. Stroke adjustment is also a fast electric adjustment and manual adjustment of the stomach.
3, bending notch, notch in general to choose the thickness 8 times the width of the. Such as plate bending 4mm, need to choose about 32 slot.
4, after the adjustment of the material is generally electric fast adjustment and manual adjustment, the same method with plate cutting machine.
5, step on the foot switch to start bending, bending machine and cutting machine is different, can be at any time to loosen, loosen the foot bending machine will stop
